What is SCADA?
A SCADA (Supervisory Control and Data Acquisition) system combines software and hardware to monitor and control industrial processes in real time. It acts as a central nervous system for large-scale operations, enabling operators to oversee and manage equipment, machinery, and processes across various industries such as manufacturing, energy, oil & gas, water treatment, and utilities.
SCADA Equipment and Devices
SCADA Equipment and Devices refers to the general physical components that make up a SCADA system.
- Field Devices: to measure, record and transmit information about processes like flow, temperatures, pressures and valve states
- Control systems: to interface to sensors like PLCs and RTUs
- Servers: whether virtual or physical, that run the SCADA host and/or Data Historian(s).
- HMIs: Screens or graphical interfaces for users to interface with to view or control the sensors mentioned
Components of a SCADA System
A SCADA system uses a collection of components working in harmony to oversee, manage, and gather information from industrial operations. These components facilitate smooth communication between physical devices in the field and the software that operators utilize to manage these processes.
Field devices are physical devices that are generally deployed ‘in the field’ which interact directly with industrial processes.
Sensors and Transmitters: measure, record and transmit information about processes like level, temperatures, and pressures
Actuators: devices like valves, motors, or relays that control the physical process.
Meters: devices that measure flow and calculate volume of produced or process liquids and gases.
Programmable Logic Controllers (PLCs) are industrial-grade computers used to control and automate processes. They are highly reliable and customizable, making them widely used in SCADA systems to control machinery and execute control logic. PLCs communicate directly with the SCADA software, gathering data and sending commands.
Remote Terminal Units (RTUs) are microprocessor-based devices that gather data from field devices (such as sensors) and transmit it to the central SCADA system. They can also send control commands to field devices based on operator input or automated rules from the SCADA system. RTUs are commonly used in remote locations.
SCADA software is responsible for managing data, displaying real-time system status, and providing control interfaces for operators. Functions of SCADA software include:
Human-Machine Interface (HMI): The user interface where operators monitor system performance and control the industrial process.
Data Logging and Reporting: Collection of historical data for analysis, performance tracking, and system optimization.
Alarm Management: Notification and escalation of abnormal conditions (e.g., high temperatures, low pressure).
A data historian is a specialized database that collects and stores time-stamped data from the SCADA system for long-term use. This allows for detailed trend analysis, reporting, and optimization. The historian is crucial for understanding process performance over time and for troubleshooting issues.
Human Machine Interfaces (HMIs) are the graphical interface that displays system data to operators. It presents real-time and historical data in a visual format (e.g., charts, gauges, process diagrams), allowing operators to quickly interpret information and make informed decisions. It also enables manual control, such as starting or stopping equipment, adjusting settings, or acknowledging alarms.
SCADA Security
SCADA security involves protecting Supervisory Control and Data Acquisition (SCADA) systems from unauthorized access, attacks, and other threats. It encompasses measures like network security, access control, encryption, and regular monitoring to ensure the integrity, availability, and confidentiality of critical industrial operations and data. Security is an increasingly important aspect of SCADA systems, which can be vulnerable to attack from various entry points. Learn about cyber security for SCADA systems.
SCADA Case Studies
Commonly Asked Questions about Industrial Automation
PLCs focus on real-time control of machinery and processes at the device level, SCADA systems provide higher-level supervisory functions, including data acquisition, visualization, and control at the system level. PLCs and SCADA systems often work together within industrial automation architectures to provide seamless control and monitoring of complex processes.
No, SCADA is not a programming language – it is a system used for monitoring and controlling industrial processes. However, within a SCADA system, programming languages may be used for various purposes.
In layman’s terms, SCADA (Supervisory Control and Data Acquisition) is like a central nervous system for industrial operations. Just as your nervous system sends and receives signals throughout your body to control and monitor its functions, SCADA does the same for machines and processes in factories, power plants, water treatment facilities, and other industrial settings.
The main purpose of SCADA (Supervisory Control and Data Acquisition) is to monitor, control, and supervise industrial processes and infrastructure in real-time.
